8
HDMI 1.3 connection
HDMI is a standard, uncompressed, all-digital audio/video interface. HDMI pro-
vides an interface between sources, such as set-top boxes, DVD players, and
receivers and your projector. Plug an HDMI cable into the video-out connector on
the video device and into the HDMI connector on the projector.
To take advantage of HDMI 1.3 Deep Color (30 bit) you must have a 1.3-compati-
ble source.
Note that the projector has no audio capabilities, so audio signals transferred
through HDMI will not be audible.
DVI connection
If your video device uses a DVI connector, plug the DVI end of an M1-DA cable
into the video-out connector on the video device. This connector may be labeled
“To Monitor” on the video device. Plug the M1-DA end of the cable into the M1-
DA/DVI connector on the projector.
Component (RCA) connection
If your device uses component connectors, plug a component video cable with red,
green, and blue RCA connectors into the source device’s component connectors
and the Component connectors on the projector.
S-video connection
If your video device uses a round, four-prong S-video connector, plug the
S-video cable into the S-video connector on your video device and into the S-
video connector on the projector.
Composite (RCA) video connection
Plug the composite video cable’s yellow connector into the video-out connector
on the video device. Plug the other yellow connector into the yellow Composite
connector on the projector.
Computer connections
You can connect a computer’s VGA connector to the M1-DA/DVI input on the
projector using an M1-A cable.
RS-232 connections
You can control the projector from an LCD control panel or computer by con-
necting an RS-232 cable to the projector’s Serial control connector. Specific RS-
232 commands can be found in the Service section of our website at www.info-
cus.com/support.
K1 RG.fm Page 8 Thursday, September 27, 2007 10:24 AM
