4. UNPACKINGANDINSTALLING
4.1 Package Contents 17
4.2 Installation Options 17
4.3 Placement Distance from Screen 18
4.4 Clearance 22
4.5 Ceiling Mount 23
4.6 Mounting Hole Diagram 24
5. ADJUSTING
5.1 Adjusting the Image Height and Tilt 25
5.2 Adjusting the Zoom, Lens Shift, and Focus 25
5.3 Adjusting the Vertical or Horizontal Keystone 26
6. CONNECTING
6.1 Connection Diagram 28
7. USING
7.1 LEDs 29
7.2 Keypad 29
7.3 Remote Control 30
7.4 Remote Effective Range 32
