43
SplitScreen Second
Source
0:off
1: VGA
2: HDMI1
3: HDMI 2
4: Component 1
5: Component 2
6: Component 3
7: S-video
8: Composite
SSL at RW 0 6 0
SplitScreen Second
Source L
ocation
0:right
1: bottom
2: left
3: top
4: bottom right
5: bottom left
6: top left
7: top right
SSY at RW 0 7 0
SplitScreen Second
Source Size
0: small
1: medium
2: large
SSZ at RW 0 2 2
SplitScreen Swap
0: n/a
1: enable
SSS at W 0 1 n/a
Standby Power
Save
SPS at RW 0 1 1
Startup Logo
0: blank screen
1: default
2: captured
SHP at RW 5 9
Sync Threshold
Setting
STH at RW 0 100 0
System State
Setting
SYS at R
Take Snapshot
Co
mmand
CAP at RW 0 1 0
Test Pattern Select
Setting
TPS at RW 0 14 0
Tint TNT at RW 0 100 50 1
Tracking MTS at RW -20 +20 0 1
Vertical Keystone DKV at RW 0 100 50 1
Vertical Position VPS at RW 0 100 50 1
Vertical Refresh
Fre
quency
QVR at R
Video Standard VSU at RW 0 5 0
Red Offset
Green Offset
Blue Offset
RCO at RW
GCO at RW
BCO at RW
0 100 50
