25
6.1.2. Liquid Crystal Display (LCD)
ENERGY FLOW DIAGRAM is located at the left side and the measurements/informations are
located at the right of LCD.
You may find the information of some Symbols on the LCD Display Panel as below;
Bypass Mode:
