56
09
Output
frequency
50Hz (default)
60Hz
11
Maximum
utility charging
current
Note: If the
setting value in
program 02 is
smaller than
that in
program in 11,
the inverter
will apply the
charging
current from
program 02 for
the utility
charger.
Available options in 1K model:
10A
20A (default)
Available options in 2K/3K model:
20A
30A (default)
Available options in 4K/5K model:
2A
10A
20A
30A (default)
12
Setting voltage
point back to
utility source
when selecting
“SBU priority”
or “Solar first”
in program 01.
Available options in 1K model:
11.0V
11.3V
11.5V (default)
11.8V
12.0V
12.3V
12.5V
12.8V
Available options in 2K/3K model:
22.0V
22.5V
