INFOSEC Nomad Combo C2 - Operating Mode Description; Operation Mode

INFOSEC UPS SYSTEM – 4 rue de la Rigotière – 44700 Orvault – France – www.infosec-ups.com
Hot Line Tel : +33 (0)2 40 76 15 82 – fax : +33(0)2 40 94 29 51 – hotline@infosec.fr – 05 14 AA 59 203 02
64
Main CPU version checking
Main CPU version 00014.04
Secondary CPU version checking
Secondary CPU version 00003.03
Operating Mode Description
Operation mode
Description
LCD display
Standby mode / Power
saving mode
Note:
*Standby mode: The inverter is
not turned on yet but at this
time, the inverter can charge
the battery without the AC
output.
*Power saving mode: If
enabled, the output of inverter
will be off when connected load
is pretty low or not detected.
No output is supplied by the
unit but it can still charge the
batteries.
Charging by utility and PV energy.
Charging by utility.
Charging by PV energy.
No charging.
