Structure with master
Structure without master
Sync message is produced by one XtrapulsPac-ak drive.
Objects definition
Index Object Name Type Attr.
0x3821 RECORD Digital Inputs Assignment rw
0x3822 RECORD Digital Outputs Assignment rw
0x3823 RECORD Analog Input Assignment rw
0x3824 RECORD Analog Output Assignment rw
0x3825 RECORD Communication Parameters rw
0x3828 RECORD Control Parameters rw
0x3829 RECORD Inputs/Outputs values rw
