Infranor XtrapulsPac - Page 38

38
X
trapulsPac – User Guide
Chapter 3 - Referenc
e
Object 0x1603: 4th Receive PDO Mapping
Index 0x1602
Name 4th Receive PDO Mapping
Object Code RECORD
Number of Elements 0..4
Value Description
Sub Index 0
Description number of mapped objects
Data Type Unsigned8
Access rw
PDO Mapping No
Default Value 1
Sub Index 1
Description 1st mapped object
Data Type Unsigned32
Access rw
PDO Mapping No
Default Value
Transmit PDO Parameter
Object 0x1800: 1st Transmit PDO Parameter
Index 0x1800
Name 1st Transmit PDO Communication Parameter (TPDO1)
Object Code RECORD
Number of Elements 2
Value Description
Sub Index 1
Description COB-ID
Data Type Unsigned32
Access rw
PDO Mapping No
Default Value 0x180 + Node-ID
Sub Index 2
Description Transmission Type
Data Type Unsigned8
Access rw
PDO Mapping No
Default Value 253
