6.3. Examples of usage
1. Routing from H/W IN to WDM IN
H/W IN 1/2 & 3/4 are routed to WDM IN 1/2
2. Routing from H/W IN to ASIO IN
H/W IN 1/2 is routed to ASIO IN 1/2 and H/W IN 3/4 is routed to ASIO IN 3/4
3. Routing from WDM OUT to ASIO IN
WDM OUT 1/2 is routed to ASIO IN 1/2. This way you can record the playback signal of
WDM applications in an ASIO application.
