IS (InfraSonic) Line / Headphone Drivers
In the analog output circuit of QUARTET there is no need to classify between line output
and headphone output.
The output jacks automatically know the difference between stereo headphone jacks or
line outputs to your speakers or mixer.
A noise shaping filter and high grade film-capacitors in the output ports can block
“Quantization noise” in the DACs (Digital Audio Converters) perfectly.
With a wide frequency response it plays back sound as close to reality as possible.
Virtual I/O Channels
QUARTET is equipped with 4X4 physical channels. It also supports virtual extended 4X4
channels, which can be easily mapped through FREE mixer.
FREE (Flexible Routing Enhanced Engine) Mixer
With FREE mixer, it is possible to connect to every part of the hardware in/outputs, WDM
and ASIO drivers to themselves.
You can use them altogether to mix and route more freely.
Depending on your setup, it can be used as input monitor, sub mixer, connection between
drivers or any purpose you want.
V-Balanced I/O
Use Quartet as balanced 2 In / 2 Out interface instead of unbalanced 4 In / 4 Out. The IO
type selection is available through a simple click on the “VB IN” and / or “VB OUT”
buttons in the control panel of the driver. V-balanced Driver provides not only a simple
alternative IO type, but also provides easy control and flexibility over the number of IO
channels. It can be changed to 4 unbalanced inputs X 2 balanced outputs, 2 balanced
inputs X 4 unbalanced-outputs or 2 balanced in and outputs. You have the freedom of
choice for any of your system setups.
1.2. What’s in the box
QUARTET PCI card
External I/O cable
TRAKTOR 3 LE Bundle CD (Optional)
Magix Samplitude 9 SE installation CD (Optional)
Driver installation CD
Four screws and isolators for the noise guard bracket
This Manual
