Ingenico group AXIUM DX8000-BASE-W2 User Manual

5
Port
a DC12V JACK port
a RJ45 network port
two USB A HOST port supporting USB2.0
a USB B DEVICE port supporting USB2.0
Power
Every USB HOST output: 5.0VDC 0.5A
Charge output: 5.0VDC 2.0A
Power adapter: input 100-240V AC, 50/60Hz; output 12V DC 3.33A
Size and Weight
Size：193.8mmx89mmx38.6mm
Net Weight：0.20kg
Gross Weight：0.70kg
2.2 Environmental Conditions
Environmental conditions for running, storing and delivering the product：
Temperature
Running
0℃～40℃
Storage and Delivery
-20℃～70℃
Humidity
Running
10％～90％
Storage and Delivery
5％～90％（40℃）
Atmospheric pressure
86kPa～106 k Pa; Below 2000 meters above sea
level
2.3 Product Functions
The base has three main functions as below:
 DX8000 charging：Connect the base with the power adapter, then place DX8000 on the base to get
charged.
 Serves as extended communication ports of DX8000: Network port, USB port, etc.
 Typical applications: Enables DX8000 to communicate with host computer via USB port, and get
Ethernet through Network port.
