4.4 Peripheral Cable Connections
Figure 4-4
When the cover behind the base is removed, the ports from left to right are as follows:
RJ45 Internet port, USB Type-A port, audio port, RS232 port, Cash drawer port and DC-JACK
port.
Notice: Please put the power cable, USB cable and Ethernet cable in the
slot of the back cover to prevent the cables from being scattered.
DC-JACK
Terminal adapter interface. Insert the random configuration of DC adapter socket for terminal power supply.
Item Signal Function
1 VDD DC 19V~20V 3.25A
2 GND GND
