GENERAL INFORMATION
12
M4 M5,5 M7,5 M11
M4 M5,5 M7,5 M11
ELECTRICAL DATA
Standard voltage 3 ~ 400V 3 ~ 400V 3 ~ 400V 3 ~ 400V
Drive motor
Power 4,0 kW 5,5 kW 7,5 kW 11,0 kW
Full load current
(maximum)
8,1 A 11,3 A 15,3 A 23,0 A
Starting current (approx.) 28,3 A 39,5 A 53,5 A 80,5 A
Starting time 6 S 6 S 6 S 6 S
Starts per hour 20 IP23/54 20 IP23/54 20 IP23/54 10 IP23/54
Fan motor
Power 80 W 160 W 160 W 240 kW
Control voltage
Control 110 VAC 110 VAC 110 VAC 110 VAC
Mains supply cable (cross
section)
1
PVC/PVC
4 mm
2
Cu 4 mm
2
Cu 4 mm
2
Cu 6 mm
2
Cu
Fuse rating
2
16 A 16 A 20 A 32 A
1
Local Regulations apply if stricter than above.
The voltage drop must not exceed 5% of the nominal voltage.
It may be necessary to use cables with a larger section than those
stated to comply with this requirement.
2
gG
NOTE
All data applies to standard product only.
