OPTIONS
28
M4 M5,5 M7,5 M11
RETIREMENT
At the end of the life cycle of the refrigerant compressed air dryer, there
are some points that deserve special attention:
1. The refrigerant is to be pumped from the refrigerant system.
When pumped, the refrigerant can be regenerated and reused when
observing local regulations.
2. The compressor contains oil.
This oil is to be removed from the compressor and can be disposed of
when observing local regulations.
3. Piping and heat exchanger are made of copper.
Copper can be reused when observing local regulations.
4. The (white) isolating foam and (black) armaflex isolation is
produced environmentally friendly.
The isolating material can be disposed of when observing local
regulations.
The remaining part of the dryer can be disposed of, observing local
regulations.
Specifications of the dryer
Model 4kW 5,5kW 7,5kW 11kW
Pressure drop over
dryer
0,22 0,18 0,20 0,25 bar
Compressor current 1,3 3,1 3,1 3,1 A
Current per fan motor 0,1 0,2 0,2 0,2 A
Total current 1,4 3,3 3,3 3,3 A
Starting current 8,2 18,0 18,0 18,0 A
Recommended fuse 16 16 16 16 A
Compressor power 0,23 0,51 0,51 0,51 kW
Fan motor power 0,02 0,04 0,04 0,04 kW
Total power 0,25 0,55 0,55 0,55 kW
The above data is quoted at reference conditions as follows:
Ambient
Temperature 25 _C
Pressure 1 bar
(a)
Relative humidity 60 %
Compressed air inlet
Temperature 35 _C
Pressure 7 bar
(g)
Relative humidity 100 %
Compressed air outlet
Pressure dew point 3 _C
Factory set controls
The constant pressure valve and the fan thermostat are factory set to
ensure the optimum performance of the dryer. These devices need to
be replaced when faulty.
AIR COOLED 4kW 5,5kW 7,5kW 11kW
Constant Pressure
Valve suction pressure
at zero load at the
moment of fan motor
switch–off.
2,05 2,05 2,05 2,05 bar
(g)
Fan thermostat – out 39 39 39 39 _C
Fan thermostat – in 56 56 56 56 _C
Refrigerant R134a R134a R134a R134a
Weight 290 420 420 420 g
Dangerous Substances
The information below is copied completely from DuPonts Material
Datasheet in February 1998.
1. Identification of the substance and of the company
Product name: SUVA
*
R–134a Refrigerant
*
DuPont’s registered trade mark
Supplier:
Du Pont (U.K.) Limited
Wedgwood Way, GB–Stevenage,
Herts. SG1 4QN
Emergency phone number: (+44) 1504 – 861 313
2. Composition / information on ingredients
Substance / preparation:
1,1,1,2–Tetrafluoroethane (R134a) Weight (%): 100 CAS Nr:811–97–2
EEC Nr: 212–377–0
3. Hazards identification
Most important hazards: Vapours are heavier thant air and can cause
suffocation by reducing oxygen available for breathing.
Specific hazards: Rapid evaporation of the liquid may cause frostbite.
4. First aid measures
General advice: Never give anything by mouth to an unconscious
person.
Inhalation: Move to fresh air. Oxygen or artificial respiration if needed.
Do not give arenaline or similar drugs.
Eye contact: Rinse thoroughly with plenty of water for at least 15
minutes and consult a physician.
Skin contact: Wash off immediately with plenty of water. Take off all
contaminated clothing immediately.
5. Fire fighting measures:
Suitible extinguishing media: any
Specific hazards: Pressure build–up
Specific methods: Cool containers / tanks with spray water.
6. Accidental release measures
Personal precautions: Evacuate personel to safe areas. Ensure
adequate ventilation. Use personal protective equipment.
Environmental precautions: Evaporates.
