36 IDS800 INSTALLER MANUAL NO. 700-175-02N ISSUED JUL 2003 VER 1.45
IDS800 INSTALLER MANUAL
Table 9: Alarm reporting codes
eulaV noitpircseD sAdetropeR
01yralgruB0311
1retemireP1311
2roiretnI2311
3)efaS(ruoH423311
4tixE/yrtnE4311
5thgin/yaD5311
6roodtuO6311
7repmaT7311
8mralaraeN8311
EXAMPLE
Assuming for a given installation it is required to differentiate between
entry/exit, interior and general burglary zones, and assuming that zone
1 is a front door (entry/exit zone), zone 2 is an interior PIR (interior
zone) and zone 3 is a general burglary zone.
Program the following locations
1. Location 86 (Zone 1) = 4 (Code 1134 = ENTRY/EXIT)
2. Location 88 (Zone 2) = 2 (Code 1132 = INTERIOR)
3. Location 90 (Zone 3) = 10 (Code 1130 = BURGLARY)
NOTES:
Although zone reporting codes for all other formats require that
both digits are programmed, the panel will only use the first digit
of the reporting code for this application. It is therefore only
necessary to program the required value into digit 1 of the relevant
zone reporting code.
NOTES ON PAGER FORMAT
The pager format transmits to an automatic digital pager. All
communication takes place with the pager network in DTMF format. It
will be necessary to check with the paging company to ensure that
this format is supported in the area as not all pager systems support
this format. To use this format the panel must be programmed as
follows:
1. Program the phone numbers into locations 48-63 and locations
