Integriti. Colour Graphic Terminal User Manual.
Monday, 18th Apr 11:25am
Library is Off
Integriti by Inner Range
Menu Temp 25.3°C Logon
Default LCD Display.
A number of options are offered for the Default display that will be shown when no
User operations are being performed, and no other messages are being displayed.
The Default display can be selected separately for each Terminal in your system.
Settings can only be programmed by the Installer, who can also advise you on the
appropriate options. If no specific Default Display option has been chosen, the
Integriti logo will be displayed. See image on front cover.
TIME & DATE.
The current system Time & Date may be displayed
in one of 3 formats:
- Single text line at the top or bottom of the screen.
- Digital Clock with date below.
- Analogue Clock in top left-hand corner.
(The Text and Digital Clock options are shown
opposite)
This is useful in systems that generate Time-On-
Site reports to show the Date & Time being logged.
SINGLE AREA STATUS.
This option allows the name and current status of a
single Area to be displayed. This is useful when
the Terminal only provides control of one Area.
LCD MESSAGES.
This feature provides one or more customized
messages that are appropriate for the particular Site
and/or the particular Terminal.
e.g. -The Monitoring Station’s Phone number.
-The Installer’s Phone number.
-“Welcome to <your company name>”.
Monday, 18th Apr 11:25am
Friday, 16th Aug 2013
12
:
48 PM
TERMINAL
