InnovaPrep CP Select - 8.4 SELECTING A PROTOCOL; 8.5 CREATING A CUSTOM PROTOCOL

Copyright 2018, InnovaPrep LLC Patented https://www.innovaprep.com/patents
27
TABLE 8.1 DEFAULT PROTOCOL MENU PARAMETERS
Protocol
Name
Valve
Open
ms
Pulse
Foam
Factor
Valve
Closed
ms
Flow
Start
sec.
Flow
End
sec.
Flow Min
Start
sec.
Ext
Delay
sec.
Pump
%
Ext Pump
Delay
sec.
FLAT
275
1
0
100
3.0
0.2
20
3
100
1
HOLLOW
575
1
10
100
3.0
0.2
20
3
100
1
ULTRA
800
2
10
100
3.0
0.2
40
3
100
1
8.4 SELECTING A PROTOCOL
8.4.1 SELECTING A PROTOCOL TO RUN
Step 1 – From the Run Protocol Menu select FLAT (or the last protocol name). This will advance you to the
Protocol Setup menu.
Step 2 – Select Select Protocol. Using the Up arrow ( ▲ ) and Down arrow ( ▼ ) you may now go to each
available Protocol and then select the desired Protocol by pressing the Enter (
⏎
). You will then be returned to
the Run Protocol menu.
8.4.2 SELECTING A PROTOCOL TO VIEW
Step 1 – From the Run Protocol Menu select FLAT (or the last protocol name). This will advance you to the
Protocol Setup menu.
Step 2 – Select Select Protocol. Using the Up arrow ( ▲ ) and Down arrow ( ▼ ) you may now go to each
available Protocol and then select the desired Protocol by pressing and holding Enter (
⏎
). You will then be
taken to a menu with the Protocol name at the top and standard or advanced settings for the protocol below.
Standard settings will be shown if Protocol: Std has been previously selected in the System Settings. Advanced
settings will be shown if Protocol: Adv has been previously selected in the System Settings. This process is
described in Section 5.4 The Instrument Settings Menu.
8.5 CREATING A CUSTOM PROTOCOL
8.5.1 NAMING A CUSTOM PROTOCOL
Step 1 – From the Run Protocol menu select the default protocol named for the tip type you plan to use for
your custom protocol (this will ensure that the appropriate advanced options will transfer to the new
protocol) This will advance you to the Protocol Setup menu.
Step 2 – Select Create Protocol. You will be prompted to create a name for your protocol. Using the Down arrow
( ▼ ) on the control panel to cycle through numerical and alpha characters sequentially from 1.9 followed by A
– Z. The Up arrow ( ▲ ) will cycle through these options backwards. To select a character, press Enter (
⏎
).
Advance to the next menu by pressing and holding Enter (
⏎
).
8.5.2 CREATING THE CUSTOM PROTOCOL SETPOINTS
Step 1 – You will then be taken to a menu with the created Protocol name at the top and standard or advanced
settings for the protocol below. Standard settings will be shown if Protocol: Std has been previously selected in
