9
Type BF Equipment
Indicates Error Signal
Indicates battery location and positioning
Indicates impulse, STIM button
Indicates connector location for optional
Patient Foot Sensor
Indicates input/output connector location
for WalkLink
Indicates exercise button
Important safety instructions
2.0 Symbols and Definitions
