INOV8 Model F240 – Edited September 2008
2
WARRANTY IS VOID IF …
1. The heater is not installed in accordance with these instructions and applicable
codes and ordinances.
2. The wiring is not in accordance with drawings in this manual.
3. The Furnace or burner is not maintained in accordance with maintenance
requirements – particularly failure to clean the combustion chamber and heat
exchanger on a regular basis.
4. Other than specified fuel is burned.
5. Fuel input capacity is over the rated condition of maximum flow rate of 1.68 US
gallons or 7.63 liters per hour.
Note: Information on the Limited Warranty was sent along with the sales order.
DISPOSAL
Dispose of packaging in an environmentally responsible manner. Dispose of all heating
system components that have to be replaced at an authorized disposal site. Dispose of
ash in a responsible manner.
UNPACKING & INSPECTING
Immediately upon receipt, check the cabinet and burner for any damage that may have
occurred in shipment. If damage is found, INOV8 or the sales representative must be
notified within two days in order to process shipping damage claims. Prior to shipping, all
components were inspected and the burner test fired, so the burner will still have oil in it.
MINIMUM CLEARANCES
Furnaces must be installed so that the following clearances are provided for proper air
movement, service and distance from combustible materials. In addition to walls and
ceilings, combustibles include rags, paper, or any moveable combustibles like gasoline
or other flammable fluid.
Inches Millimeters Purpose
Cabinet Fan Motor: 6 152 air movement
Chimney connector (flue pipe): 18 457 combustible material
Above Furnace: 24 609 combustible material
Below Furnace: 4 101 combustible material
Burner side: 48 1,219 service access
Outlet Louver: Unobstructed air movement
