5. Configuration
Table 3 describes all of the configuration options for the Inova OnTime Clock. The
recommended configuration method is to add private options to the DHCP server so
that all the clocks can be configured and reconfigured quickly and easily. (See Section
6.)
Automatic
Configuration,
See Section 6
Manual
Configuration,
See Section 7
Network
Parameters
These settings allow the clock to be part of the local network
IP Address
DHCP
Telnet
Subnet Mask
DHCP Standard option 1
Telnet
Default Gateway
DHCP Standard option 3
Telnet
DNS Server
DHCP Standard option 6
Telnet
Time
Parameters
These settings allow the clock to access and display network time.
Time Server, primary
DHCP Private option 230
Telnet
Time Server,
secondary
Telnet
Telnet
Time Zone
DHCP Private option 230
Telnet
Daylight Savings Time
(DST)
DHCP Private option 230
Telnet
Digital Clock, 12/24
hour time
DHCP Private option 230
Telnet
Digital Clock,
show/hide colon
DHCP Private option 230
Telnet
Management
Parameters
These settings allow a user to monitor the clocks and set up alerts from the support
site.
cloudserver
DHCP Private option 231
Telnet
sitetoken
DHCP Private option 231
Telnet
Table 3: Configuration Options for Inova OnTime Clock
5.1. Network Parameters
The IP Address, Subnet Mask, Default Gateway and DNS Server are required so that
the clock can communicate on the network. These parameters are set automatically if
you use DHCP.
