OnTime Clock
Installation and User Guide
Firmware Version 2
All claims based on information publicly available at time of printing. All other product or service names mentioned
in this document may be trademarks of the companies with which they are associated.
© 2017 Inova Solutions | All rights reserved | page 4
3. Technical Specifications
The OnTime Clock is available in three models with the specifications listed in Table 1.
Table 1: Technical Specifications
Analog Clock Dial
12” (30 cm)
4-Digit
Red or green 7-segment LED
6-Digit
Red or green 7-segment LED
Black injection molded
plastic
Black injection molded plastic
Putty or off-white injection
molded plastic, Black painted
aluminum, Brushed stainless
steel
PoE, IEEE 802.3af /at
compliant
Single sided: 3W
Double sided: 4W
PoE, IEEE 802.3af /at compliant
8W actual consumption
PoE, IEEE 802.3af /at compliant
9.5W actual consumption
Single sided:
12
3
/
4
” diameter x 1
7
/
8
”D
(29.5 cm x 5.1 cm)
Double sided:
12
3
/
4
” diameter x 4”D
(29.5 cm x 10.8 cm)
12”L x 6”H x 2.28”D
(30.5 cm x 15.2 cm x 5.8 cm)
17.5”L x 6”H x 2.28”D
(44.5 cm x 15.2 cm x 5.8 cm)
Single sided:
1.6 lbs (0.73 kg)
Double sided:
7 lbs (3.2 kg)
Plastic Cabinet:
1.6 lbs (0.7 kg)
Aluminum Cabinet:
2.2 lbs (1.0 kg)
Stainless Steel Cabinet:
4.1 lbs (1.85 kg)
Aluminum Cabinet:
3.25 lbs (1.47 kg)
Stainless Steel Cabinet:
5.6 lbs (2.5 kg)
32º to 104º F (0º to 40º C)
95% maximum, non-condensing
UL/CSA 60950-1, ETL Listed, CE Marked, RoHS Compliant
Three (3) years, returned to factory. Refer to Section 9 for warranty details.
