‑10‑
1.3 Specifications
■ Power supply specifications
Item Specification
Rated terminal input voltage 24 VDC (20.4 VDC to 28.8 VDC)
Rated terminal input current 0.6 A (typical@24 V)
Rated bus output voltage 5 VDC (4.75 VDC to 5.25 VDC)
Rated bus output current 2 A (typical@5 V)
Power output derating 85% derating at 55°C (the output current
does not exceed 1.7A), or 10°C derating at 2
A output
Isolation No
Power protection Overcurrent protection, anti reverse
connection protection, surge absorption
■ Software specifications
Item Specification
Access through alias The ECT module supports alias configuration and access through
its alias. Expansion modules connected to the ECT module do not
support alias configuration and access through alias. Range: 1 to
65535
PDO data size: input 1,024 bytes max.
PDO data size:
output
1,024 bytes max.
Mailbox data size:
input
256 bytes max.
Mailbox data size:
output
256 bytes max.
