8
2 Mechanical Design Reference
Mounting Dimensions
53.2
90
88.5
97.5
Figure 3 Mounting dimensions diagram (in mm)
3 Electrical Design Reference
Cable Preparation
$BCMFDPOOFDUPS1$QSPOH
"8($BUFTIJFMEFEUXJTUFEQBJS
$BCMFDPOOFDUPS1$QSPOH
Figure 4 EtherCAT cable preparation
4IJFMEFEDBCMF 6OTIJFMEFEDBCMF
Use Cat 5e shielded twisted pair (STP) cables, with injection molded and iron
shelled connector.
