6.10.4 Write Frequency Reference
You can set frequency reference, torque limit, V/F separation voltage, PID reference and PID
feedback via communication address 1000H. The data range is -10000 to 10000, corresponding
to -100.00% to 100.00%.
)RUH[DPSOHWRVHWPDLQIUHTXHQF\UHIHUHQFHWRE\XVLQJ0RGEXVSURWRFRO¿UVWVHW)
= 9 and send write command 01 06 10 00 1F 40 84 CA. In the command,
Ɣ
01H (settable): AC drive address
Ɣ
06H: write command
Ɣ
1000H: communication address of giving the frequency reference
Ɣ
1F40H: frequency reference (converted into decimal 10000)
Ɣ
84CAH: CRC check
Note
Range of frequency reference given via communication is -10000 to 10000,
corresponding to -100.00% to 100.00%. -100.00% corresponds to negative
maximum frequency, 0.00% corresponds to minimum frequency, and 100.00%
corresponds the maximum frequency.
Suppose that F0-10 = 50 Hz, if frequency reference in write command is 1F40H,
converted to decimal 8000, frequency reference that is written is 50 x 80.00%
= 40 Hz.
Sending Message Response Message
ADDR 01H ADDR 01H
CMD 06H CMD 06H
Parameter address high bits 10H Parameter address high bits 10H
Parameter address low bits 00H Parameter address low bits 00H
Data content high bits 1FH Data content high bits 1FH
Data content low bits 40H Data content low bits 40H
CRC high bits 84H CRC high bits 84H
CRC low bits CAH CRC low bits CAH
