Appendix
- 342 -
12
B.3 Monitoring Function Codes
Para. No. Para. Name Display Range Page
Group U0: Monitoring Parameters
U0-00 Running frequency 0.00 to 500.0 Hz
1
6
2
U0-01 Frequency reference 0.00 to 500.0 Hz
1
6
2
U0-02 Bus voltage 0.0 to 3000.0 V
1
6
2
U0-03 Output voltage 0 to 1140 V
1
6
2
U0-04 Output current 0.00 to 655.35 A
1
6
2
U0-05 Output power 0 to 32767
1
6
2
U0-07 DI state 0 to 32767
1
6
2
U0-08 DO state 0 to 1023
1
6
3
U0-09 AI1 voltage - -
U0-10 AI2 voltage -
1
6
3
U0-11 AI3 voltage - -
U0-12 Count value - -
U0-13 length value - -
U0-14 Load speed display 0 to rated motor speed
1
6
3
U0-15 PID reference 0 to 65535
1
6
3
U0-16 PID feedback 0 to 65535
1
6
3
U0-17 PLC stage - -
U0-18 Pulse reference 0.00 to 20.00 kHz
1
6
3
U0-19 Feedback speed -500.0 to 500.0 Hz
1
6
3
U0-20 Remaining running time 0.0 to 6500.0 min
1
6
3
U0-21 AI1 voltage before correction 0.00 to 10.57 V
1
6
4
U0-22 AI2 voltage (V)/ current (mA) before
correction
0.00 to 10.57 V
1
6
4
U0-23 AI3 voltage before correction -10.57 to 10.57 V
1
6
4
U0-24 Motor speed 0 to rated motor speed
1
6
4
U0-25 Accumulative power-on time - -
U0-26 Accumulative running time - -
U0-27 Pulse reference 0 to 65535 Hz
1
6
4
U0-28 Communication reference -100.00% to 100.00%
1
6
4
U0-30 Main frequency reference 0.00 to 500.00 Hz
1
6
4
U0-31 Auxiliary frequency reference 0.00 to 500.00 Hz
1
6
4
U0-32 Viewing any register address value - -
U0-34 Motor temperature -
1
6
4
To Next Page
