Inovance MD290T45G/55P User Manual

8. Peripherals and Options
- 254 -
8
Ƶ
Extension PROFIBUS-DP Card (MD38DP2)
MD38DP2, complying with international PROFIBUS field bus standard, is designed to
FRQQHFWWKHGULYHWR352),%86'3EXV7KLVFDUGFDQLPSURYHFRPPXQLFDWLRQHI¿FLHQF\
and implement AC drive networking function. It enables the drive to be a slave in the bus,
controller by the master.
Besides PROFIBUS-DP communication, MD38DP2 provides CANlink communication
interface.
*1'
&$1/
&$1+*1'
J6
J3
SW1
J9
ON
1
2
3
456
7
8
J2
S1
D2 D3
D4
Table 8-15 Terminal descriptions of MD38DP2
Type Terminal Terminal Name Function Description Terminal Arrangement
PROFIBUS
communication
terminal (J2)
1, 2, 7, 9 NC Vacant internally
1
2
3
4
5
6
7
8
9
RTS
GND
+5V
Data line A
NC
NC
NC
NC
Data line B
3 Data line B Data line positive
4 RTS Request of sending
signal
5 GND Isolation 5 V power
ground
6 +5V Isolation 5 V power
supply
8 Data line A Data line negative
CANlink
communication
terminals (J3,
J9)
CANH CAN positive
input
Data line positive -
CANL CAN negative
input
Data line negative
GND Power ground Isolation 5 V power
ground
Table 8-16 Jumper descriptions of MD38DP2
Jumper Description Meaning Setting
J6 CANlink terminal resistor
matching selection
Matching the terminal resistor
Not matching the terminal resistor
