Appendix

- 287 -

Installing Fuse on the Input Side

To prevent accidents caused by short circuit, install fuse on the input side and the fuse

must comply with the UL standard.

6HOHFWWKHIXVHDFFRUGLQJWRWKHIROORZLQJ¿JXUH

Model FWH Series Fuse

Manufacturer: Bussmann

Rated Current (A) Model

MD290T18.5G/22P 80 FWH-80B

MD290T22G/30P 100 FWH-100B

MD290T30G/37P 100 FWH-100B

MD290T37G/45P 125 FWH-125B

MD290T45G/55P 150 FWH-150B

MD290T55G/75P 200 FWH-200B

MD290T75G/90P 250 FWH-250B

MD290T90G/110P 275 FWH-275B

MD290T110G/132P 325 FWH-325B

MD290T132G/160P 400 FWH-400B

MD290T160G/200P 500 FWH-500B

MD290T200G(-L) MD290T220P(-L) 600 FWH-600B

MD290T250P(-L) - 600 FWH-600B

MD290T220G(-L) MD290T280P(-L) 700 FWH-700B

MD290T250G(-L) MD290T315P(-L) 800 FWH-800B

MD290T280G(-L) MD290T355P(-L) 800 FWH-800B

MD290T315G(-L) MD290T400P(-L) 1000 170M5016

MD290T355G(-L) MD290T450P(-L) 1000 170M5016

MD290T400G(-L) MD290T500P(-L) 1400 170M6017

MD290T450G(-L) - 1400 170M6017

Preventing Entry of Foreign Objects

7KHGULYHXQLWVPXVWEHLQVWDOOHGLQD¿UHSURRIFDELQHWZLWKGRRUVWKDWSURYLGHHIIHFWLYH

electrical and mechanical protection. The installation must conform to local and regional

laws and regulations, and to relevant IEC requirements.

Grounding

If using an AC drive of the 400 V class, tie the neutral point of the drive power supply to

ground.
