Inovance MD290T45G/55P User Manual

Appendix
- 312 -
12
Para. No. Para. Name Setting Range Default Property Page
F4-01 DI2 function selection 21: Acceleration/Deceleration
prohibited
22: PID disabled
23: PLC state reset
24: Wobble disabled
25: Counter input
26: Counter reset
27: Length signal pulses count
28: Length reset
30: Pulse input as frequency
reference (valid only for DI5)
31: Reserved
32: Immediate DC injection braking
33: External fault normally-closed
input
)UHTXHQF\PRGL¿FDWLRQ
enabled
35: PID operation direction reverse
36: External stop 1
37: Command source switchover 2
38: PID integral disabled
39: Switchover between main
frequency reference and preset
frequency
40: Switchover between auxiliary
frequency reference and preset
frequency
41: Motor selection
42: Reserved
43: PID parameter switchover
8VHUGH¿QHGIDXOW
8VHUGH¿QHGIDXOW
47: Emergency stop (ES)
48: External stop 2
49: Deceleration DC injection
braking
50: Clear running time this time
51: Two-wire control/ Three-wire
control
52: Reverse running prohibited
53 to 59: Reserved
4
ƾ
1
7
8
F4-02 DI3 function selection 9
ƾ
1
7
8
F4-03 DI4 function selection 12
ƾ
1
7
8
F4-04 DI5 function selection 13
ƾ
1
7
8
F4-05 DI6 function selection 0
ƾ
1
7
8
F4-06 DI7 function selection 0
ƾ
1
4
1
F4-07 DI8 function selection 0
ƾ
1
7
8
F4-08 DI9 function selection 0
ƾ
1
7
8
F4-09 DI10 function selection 0
ƾ
1
7
8
F4-10 ',¿OWHUWLPH 0.000s to 1.000s 0.010s
ƿ
-
F4-11 Terminal I/O control mode 0: Two-wire mode 1
1: Two-wire mode 2
2: Three-wire mode 1
3: Three-wire mode 2
0
ƾ
1
0
3
F4-12 Terminal UP/DOWN rate 0.001 to 65.535 Hz/s 1.000 Hz/s
ƿ
-
F4-13 AI curve 1 min. input 0.00 V to F4-15 0.00 V
ƿ
1
1
3
F4-14 Corresponding percentage of
AI curve 1 min. input
-100.00% to 100.0% 0.0%
ƿ
1
1
3
