3. Electrical Installation
- 58 -
3
Figure 3-11 Terminal dimensions of MMD290T250G-L, MD290T280G-L, MD290T315P-L and
MD290T355P-L (without side entry copper bar, without output reactor)
S
R
T
U
V
W
36 36
14-M12
65
62
139
29
29
199.6
330
50
85
192.5
50
33
2
13
Table 3-8 Recommended cable dimensions and tightening torque of MD290T250G(-L),
MD290T280G(-L), MD290T315P(-L) and MD290T355P(-L)
AC Drive Model Rated Input
Current (A)
Power Input/
Output Cable
Crimp
Terminal
Model
Ground
Cable
Crimp
Terminal
Model
Tightening
Torque
(N·m)
Screw
Spec.
MD290T250G(-L) 441 2 x (3 x 120) mm
2
300 kcmil x 2P
150-12 120 mm
2
1/0 AWG
60-12 35.0 M12
MD290T315P(-L) 559 2 x (3 x 185) mm
2
500 kcmil x 2P
250-16 185 mm
2
2/0 AWG
70-16 35.0 M12
MD290T280G(-L) 495 2 x (3 x 150) mm
2
400 kcmil x 2P
200-12 150 mm
2
1/0 AWG
60-12 35.0 M12
MD290T355P(-L) 624 2 x (3 x 185) mm
2
500 kcmil x 2P
250-16 185 mm
2
2/0 AWG
70-16 35.0 M12
Figure 3-12 Terminal dimensions of MD290T315G to MD290T450G and MD290T/400P to
MD290T500P (without output reactor)
65
62
8-M16
36
36
133
45
55
U
V
W
T
S
R
133
36
36
3- 17
340
244
85
50
49
30
2- 17
196 123123
