MD380 User Manual Function Code Table
- 83 -
Function
Code
Parameter Name
Setting Range
Default Property
F0-27
Binding command source to
frequency source
Unit's digit (Binding operation
panel command to frequency
source)
000 ☆
0: No binding
1: Frequency source by digital
setting
2: AI1
3: AI2
4: AI3
5: Pulse setting (DI5)
6: Multi-reference
7: Simple PLC
8: PID
9: Communication setting
Ten's digit (Binding terminal
command to frequency source)
0–9, same as unit's digit
Hundred's digit (Binding
communication command to
frequency source)
0–9, same as unit's digit
F0-28
Serial communication
protocol
0: Modbus protocol
1: Probus-DP bridge
2: CANopen bridge
0 ☆
Group F1: Motor 1 Parameters
F1-00 Motor type selection
0: Common asynchronous motor
1: Variable frequency
asynchronous motor
2: Permanent magnetic
synchronous motor
1 ★
F1-01 Rated motor power
0.1–1000.0 kW
Model
dependent
★
F1-02 Rated motor voltage
1–2000 V
Model
dependent
★
F1-03 Rated motor current
0.01–655.35 A (AC drive power ≤
55 kW)
0.1–6553.5 A (AC drive power >
55 kW)
Model
dependent
★
F1-04 Rated motor frequency
0.01 Hz to maximum frequency
Model
dependent
★
F1-05
Rated motor rotational
speed
1–65535 RPM
Model
dependent
★
