Function Code Table
MD380 User Manual
- 84 -
Function
Code
Parameter Name
Setting Range
Default Property
F1-06
Stator resistance
(asynchronous motor)
0.001–65.535 Ω (AC drive power
≤ 55 kW)
0.0001–6.5535 Ω (AC drive
power > 55 kW)
Model
dependent
★
F1-07
Rotor resistance
(asynchronous motor)
0.001–65.535 Ω (AC drive power
≤ 55 kW)
0.0001–6.5535 Ω (AC drive
power > 55 kW)
Model
dependent
★
F1-08
Leakage inductive reactance
(asynchronous motor)
0.01–655.35 mH (AC drive power
≤ 55 kW)
0.001–65.535 mH (AC drive
power > 55 kW)
Model
dependent
★
F1-09
Mutual inductive reactance
(asynchronous motor)
0.1–6553.5 mH (AC drive power
≤ 55 kW)
0.01–-655.35 mH (AC drive
power > 55 kW)
Model
dependent
★
F1-10
No-load current
(asynchronous motor)
0.01 to F1-03 (AC drive power ≤
55 kW)
0.1 to F1-03 (AC drive power >
55 kW)
Model
dependent
★
F1-16
Stator resistance
(synchronous motor)
0.001–65.535 Ω (AC drive power
≤ 55 kW)
0.0001–6.5535 Ω (AC drive
power > 55 kW)
Model
dependent
★
F1-17
Shaft D inductance
(synchronous motor)
0.01–655.35 mH (AC drive power
≤ 55 kW)
0.001–65.535 mH (AC drive
power > 55 kW)
Model
dependent
★
F1-18
Shaft Q inductance
(synchronous motor)
0.01–655.35 mH (AC drive power
≤ 55 kW)
0.001–65.535 mH (AC drive
power > 55 kW)
Model
dependent
★
F1-20
Back EMF (synchronous
motor)
0.1–6553.5 V
Model
dependent
★
F1-27
Encoder pulses per
revolution
1–65535
1024 ★
F1-28 Encoder type
0: ABZ incremental encoder
1: UVW incremental encoder
2: Resolver
3: SIN/COS encoder
4: Wire-saving UVW encoder
0 ★
F1-30
A/B phase sequence of ABZ
incremental encoder
0: Forward
1: Reserve
0 ★
