3 Protocol Description of the MD38CAN2
- 7 -
3 Protocol Description of the MD38CAN2
3.1 Software Feature
MD38CAN2 supports 󶍾ve protocols, described as follows:
■
NodeGuarding: The master can query the device state with this function.
■
Heartbeat: The slave reports its current state periodically to the master.
■
Service data object (SDO): Only expedited transfer is supported. Two bytes of a
parameter is transferred each time.
■
Three transmit process data objects (TPDOs) and three receive process data objects
(RPDOs)
■
Emergency (EMCY) objects
3.2 COB-ID
CANopen provides many types of communication objects (COBs), each having di󶍽erent
features (for details, see the description of the CANopen standard protocol). Di󶍽erent
communication objects are used based on the actual application scenarios. MD38CAN2
adopts the pre-de󶍾ned communication object identi󶍾ers (COB-IDs), as follows:
1) Network management (NMT) object: 0x000
2) Synchronization (SYNC) object: 0x080
3) SDO:
■
Transmit SDO: 0x600+Node-Id
■
Receive SDO: 0x580+Node-Id
4) PDO:
■
RPDO1: 0x200+Node-Id
■
RPDO2: 0x300+Node-Id
■
RPDO3: 0x400+Node-Id
■
TPDO1: 0x180+Node-Id
■
TPDO2: 0x280+Node-Id
■
TPDO3: 0x380+Node-Id
5) EMCY object: 0x80+Node-Id
■
Node-Id: Indicates the device ID (node address), and it is set by the DIP switch.
■
COB-ID is 󶍾xedly allocated and cannot be changed.
