5. Output format
5.1 Second display continuous sending format
Output continuous format
S
T
X
S
W
A
S
W
B
S
W
C
X X XXXXXXXXXX
C
R
C
K
S
1 2 3 4 5 6
State A
Bits0,1,2
0 1 2 Decimal point position
1 0 0 XXXXXX0
0 1 0 XXXXXXX
1 1 0
XXXXX．X
0 0 1
XXXX．XX
1 0 1
XXX．XXX
Bits3,4 Division
0 1 X1
1 0 X2
State B
BitsS function
Bits0 gross=0, net=1
Bits1 Symbol: positive =0,negative =1
Bits2 Overload(or under zero)=1
Bits3 dynamic=1
Bits4
unit：lb=0, kg=1
Bits5 Constant 1
