12
NS-40D420NA18 / NS-40D420MX18 / NS-49D420NA18 / NS-55D420NA18 / NS-55D420MX18
www.insigniaproducts.com
2 If the TV stands are installed, remove the four screws that secure the stands to your TV.
3 Attach the wall-mount bracket to your TV using the mounting holes on the back of your TV. See the instructions that
came with the wall-mount bracket for information about which screws to use and how to correctly hang your TV.
Notes
• The length of the wall-mount screws vary depending on the wall-mount
bracket you purchased. We recommend that you use the wall-mount
screws and spacers that came with your TV. They fit most wall-mount
brackets.
• Make sure that the screws you use are the correct length. The threaded
parts of the screws that are inserted into the back of your TV must be at
least 9.5mm in length and not more than 11.5mm in length. If the
screws are too short, your TV may fall off the wall-mount bracket. If the
screws are too long, they may damage components inside your TV. For
more information, see the instructions that came with the wall-mount
bracket.
• The mounting holes on the back of your TV take type M6 screws.
7.87 in. (200 mm)
7.87 in. (200 mm)
55" model shown
