24
NS-40D420NA18 / NS-40D420MX18 / NS-49D420NA18 / NS-55D420NA18 / NS-55D420MX18
www.insigniaproducts.com
Connecting a game console
You can connect a game console using:
•HDMI (best)
•AV (good)
HDMI (best)
1 Make sure that your TV’s power cord is unplugged and the game console is turned off.
2 Connect an HDMI cable (not provided) to an HDMI jack on your TV and to the HDMI OUT jack on the game console.
3 Plug your TV’s power cord into a power outlet, then turn on your TV and the game console.
4 Press INPUT to open the INPUT SOURCE list.
5 Press
or to highlight HDMI1, HDMI2, or HDMI3, then press ENTER.
Note
An HDMI cable carries both audio and video. You do not need to use any
audio cables.
Side of
TV
HDMI
cable
Game console
On your TV
HDMI jack
HDMI jack
HDMI cable
connector
40"/49" model
Back of TV
55" model
