9
2.0 Channel Soundbar
www.insigniaproducts.com
Back view
# ITEM DESCRIPTION
1 USB port
Connect a USB source device to play MP3/WAV files.
2 AUX IN jack
Connect a 3.5 mm audio cable to this jack.
3 HDMI (ARC) jack
Connect an HDMI cable (not included) to this jack on an
ARC-enabled sound system. Set the sound output from
the source to the PCM format.
4 OPTICAL jack
Connect a digital optical cable to this jack and the
OPTICAL OUT jack on a TV or audio source device. Set
the sound output from the source to the PCM format.
5 AC power cord
Connect the AC power cord to this jack to power the
soundbar.
HDMI (ARC)
AUX IN USB OPTICAL
