17
3-in-1 TV STAND
www.insigniaproducts.com
WALL MOUNT ASSEMBLY INSTRUCTIONS
Step 1: Select the correct bolts, washers, and spacers for your TV.
If you are in doubt about which size bolt to use, try one of the bolts in one of the four Vesa mounting holes on the
back of your TV. A bolt that is too large will be obvious and not fit in the hole at all, but make sure that the bolt size
you choose is not too loose. It should grip the hole threads evenly and not wobble. After you determine which size
bolts to use, go on to the next step.
M4 hardware assembly:
•M4 x 12 mm bolts (HH) top screw holes
•M4 x 30 mm bolts (II) bottom screw holes
•M4 lock washers (SS)
•M4/M5 Flat washers (YY)
•Small spacers (XX)
M5 hardware assembly:
•M5 x 12 mm bolts (JJ) top screw holes
•M5 x 30 mm bolts (KK) bottom screw holes
•M5 lock washers (TT)
•M4/M5 flat washers (YY)
•Small spacers (XX)
M6 hardware assembly:
•M6 x 12 mm bolts (LL) top screw holes
•M6 x 35 mm bolts (MM) bottom screw holes
•M6 lock washers (UU)
•M6/M8 flat washers (ZZ)
•Large spacers (WW)
M8 hardware assembly:
•M8 x 16 mm bolts (NN) or M8 x 20 mm bolts (PP) top screw holes
•M8 x 40 bolts (QQ) or M8 x 50 bolts (RR) bottom screw holes
•M8 lock washers (VV)
•M6/M8 flat washers (ZZ)
•Large spacers (WW)
NS-HWMC1848_17-0157_MAN_V4_ENG.fm Page 17 Tuesday, March 7, 2017 3:08 PM
