Insignia NS-LCD32-09

32″LCD TV Best Buy NS-LCD32-09
55
10. Exploded View
ITEM PART NO. PART NAME Q'ty UNIT
1 A34T0517 GM AL0130 BEZEL TV32W-8A1 1 PCS
2 A33T0307 ED 1C0100 LENS_IR 1 PCS
3 A33T0306 1 1C0100 Power Lens 1 PCS
4 IR BOARD 1 PCS
5 A33T0304 GMA1L0100 COVER_FUNC 1 PCS
6 A33T0305 QV 1L0100 BUTTON_FUNC 1 PCS
7 KEY BOARD 1 PCS
8 A15T0280102 bkt-panel-support 2 PCS
9 A15T0283102 bkt-base-support 1 PCS
10 POWER BOARD 1 PCS
11 MAIN BOARD 1 PCS
12 Q37T0078011 GM Hinge Ass'y 1 PCS
13 A34T0521 GM 1L0120 BASE_S1 1 PCS
14 A15T0384101 bkt-base-plate-a1-big 1 PCS
15 Q12T6300 25 2 RUBBER FOOT 6 PCS
16 A34T0518 GM 1A0100 REAR COVER 32 1 PCS
17 A15T0282101 bkt-vesa-btm 2 PCS
18 A15T0287301 bkt-io-us 1 PCS
19 A15T0279102 bkt-pcb-holder-btm 1 PCS
20 A15T0278102 bkt-pcb-holder-top 1 PCS
21 A15T0281102 bkt-vesa-top 1 PCS
22 750TVMM5B1111N PANEL V315B1-L01 C2 TW CMO 1 PCS
23 SPEAKER 2 PCS
31 0M1T 940 6120 SCREW 10 PCS
32 0Q1T 930 6120 SCREW 2 PCS
33 0M1T1730 6120 SCREW 3*6MM 9 PCS
34 0M1T1740 6120 SCREW 1 PCS
35 0M1T1730 10120 SCREW 2 PCS
36 0Q1T 940 14 47 CR3 SCREW 12 PCS
37 0Q1T 130 8120 SCREW 4 PCS
38 0M1T 940 10 47 CR3 SCREW 2 PCS
39 0Q1T 930 8 47 CR3 SCREW 2 PCS
40 0D1T 930 8 47 CR3 SCREW 3 PCS
41 0D1T 940 6120 SCREW 10 PCS
42 0Q1T1040 8 47 CR3 SCREW 2 PCS
TV32W08 BBY Exploding
