32〞LCD TV Best Buy NS-LCD32-09
36
8. Block Diagram
Hsync,
Vsy nc
HDMI-1
CVBS
Analog
HDMI-2
CVBS
Tuner
ENG36E21KF
CM2031
USB 1.1
IIS
IIS
EJTAG
EAR
PHONE
S-Video
AUDIO-R\L
POWER
BOARD
YPbPr
LVDS
CVBS
VGA
DDRII
NT5TU32M16BG
CVBS
AUDIO-R\L
5V,12VPOW ER- ON
Analog R/L
VIF
Analog R/L
YPbPr
S-VIDEO
GPIO
CM2031
Audio
Processor
WM8594SEFT
SIF
TMDS
SPDIF
TMDS
MCU
RTD2120L
ZR39770
M24C32
Digital
VGA AUDIO-R\L
TMDS
Audio Amplifier
STA559BW
RGB
SN74LVC1G17DBVR
LCD
PANEL
I2C
SPEAKER
Y/C
S/PDIF
M24C02
FLASH ROM
M25P32-VMF6TP
YPbPr AUDIO-R\L
TMDS
