Insignia NS-RFD26SS9 User Manual

www.insigniaproducts.com
13
NS-RFD26SS9
Removing the refrigerator doors (Optional)
If the opening to the installation area you chose is too narrow for your refrigerator to pass through, remove the doors and
drawers, then move your refrigerator sideways into the area.
You will need the following tools to remove the refrigerator doors:
1 Make sure that your refrigerator is unplugged.
2 With the refrigerator compartment doors shut, remove the three screws that secure the cover on the top of your
refrigerator, then remove the cover with the attached harness assemblies.
3 Use an 8 mm wrench to remove the three hinges screws, use a Phillips screwdriver to remove the ground screw, then
remove the hinges.
Note: Do not remove the doors unless you have to.
Phillips screwdriver
8mm wrench
5 mm Allen wrench
Flat-blade screwdriver
Top cover
Ground screw
Hinge screws
Hinge
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 13 Tuesday, June 12, 2018 9:16 AM

Insignia NS-RFD26SS9 Specifications

General

Style	French Door
Color	Stainless Steel
Number of Doors	3
Total Capacity	27.8 Cu. Ft.
Refrigerator Capacity	14.8 cu. ft.
Freezer Capacity	7 cu. ft.
Number of Refrigerator Shelves	5
Number of Refrigerator Bins	6
Humidity Controlled Crispers	2
Number of Freezer Shelves/Baskets	1 Drawer Divider
Refrigerator Temperature	-
(-14°C)	-
Refrigerator Special Features	Power Freeze and Power Cool
Freezer Special Features	DuraBase Solid Drawer Base
Defrost System	-
Noise level	-
Refrigerant	-
Energy Class	-
Annual Energy Consumption	624 kWh
Voltage	115 V
Frequency	60 Hz
Current	-

Weight and Dimensions

Depth	36 1/4 in
Height	69 5/8 in
Width	29 3/4 in
Net Weight	313 lbs
