Insignia NS-RFD26SS9 User Manual

www.insigniaproducts.com
19
NS-RFD26SS9
11 Pull the bottom of freezer compartment door away from the support frame, then lift the door up and out.
12 Move your refrigerator into its final position, then re-install the drawers and doors by reversing these steps.
Connecting the water supply
Your refrigerator comes with a water dispenser and an ice maker. To use these features, you need to connect your
refrigerator to a drinking (potable) water supply. In order for the ice maker to operate correctly, the water pressure needs
to be between 30 and 125 psi.
The following parts are included (inside the refrigerator drawer):
CAUTIONS:
• A qualified plumber should make the water connection.
• Using water pressure that is outside the 30 to 125 psi range can cause serious malfunction and severe, damaging water leaks.
Note: If you install your refrigerator in an area with low water pressure (below 30 psi), you can install a booster pump to compensate
for the low pressure.
Extension
tubing
Clips (2)
Coupler (1)
NS-RFD26SS9_18-0333_MAN_V3_EN.fm Page 19 Tuesday, June 12, 2018 9:16 AM

Insignia NS-RFD26SS9 Specifications

General

Style	French Door
Color	Stainless Steel
Number of Doors	3
Total Capacity	27.8 Cu. Ft.
Refrigerator Capacity	14.8 cu. ft.
Freezer Capacity	7 cu. ft.
Number of Refrigerator Shelves	5
Number of Refrigerator Bins	6
Humidity Controlled Crispers	2
Number of Freezer Shelves/Baskets	1 Drawer Divider
Refrigerator Temperature	-
(-14°C)	-
Refrigerator Special Features	Power Freeze and Power Cool
Freezer Special Features	DuraBase Solid Drawer Base
Defrost System	-
Noise level	-
Refrigerant	-
Energy Class	-
Annual Energy Consumption	624 kWh
Voltage	115 V
Frequency	60 Hz
Current	-

Weight and Dimensions

Depth	36 1/4 in
Height	69 5/8 in
Width	29 3/4 in
Net Weight	313 lbs
