Insignia NS-RFD26SS9 - Water Supply Installation

www.insigniaproducts.com
20
26.6 Cu. Ft. French Door Refrigerator
You will need the following tools and parts (not included):
1 Shut off the main water supply.
2 Using a 1/4" drill bit, drill a hole into the cold water line, then install the saddle-type shutoff valve.
CAUTIONS:
Make sure that you:
• Use the tubing that came with your refrigerator. Do not use old tubing.
• Connect to the cold water pipe. If you connect to the hot water pipe, the purifier may malfunction.
• Do not contaminate the water pipes during installation.
Phillips screwdriver
Flat-blade screwdriver
1/4" saddle-type
shutoff valve (1)
1/4"
compression
nut (1)
Ferrule
(sleeve) (1)
Drill
1/4" drill bit
1/2" or adjustable
wrench
Cold water line
Pipe clamp
Shutoff valve
