Insignia NS-RFD26SS9 - Hinge Bolt Removal

www.insigniaproducts.com
15
NS-RFD26SS9
5 Use a 5 mm Allen wrench to remove the four hex head hinge bolts (two per hinge) on the lower left and rights sides of
your refrigerator, then remove the hinges.
6 Pull the freezer compartment door and the upper freezer drawer fully open.
Hinge
Hinge bolts
Allen wrench
Upper freezer
drawer
