Insignia NS-RTM18BK8L User Manual

12
NS-RTM18BS8/NS-RTM18WH7/NS-RTM18SS7/NS-RTM18BKR8/
NS-RTM18WH7-C/NS-RTM18SS7-C
www.insigniaproducts.com
5 Unscrew the two screws holding the bottom hinge, then remove the bottom
hinge from the refrigerator.
6 Unscrew the hinge pin from the bottom hinge and reattach it to the other
hole in the hinge pin, then secure the bottom hinge to the opposite side of
the refrigerator using the screws you removed previously.
7 Remove the hole caps and plastic bushings from the top of the freezer and
refrigerator doors. Save them for the next step.
Remove the bottom hinge
Reattach the bottom hinge
Hinge pin
Hinge pin
Hole caps
Plastic bushings
