Inspire M1 - Top Beam Plate

Note: Attach left and right Top Beam Plates with “Inspire” logo facing out.
Right Top Beam Plate Left Top Beam Plate
1” Bolt
1” Bolt
2 - 4” Hex Bolts
2 – 1” Hex Bolts
6 - 3/8” Flat Washers
2 - 3/8” Lock Nuts
FINGER TIGHTEN ONLY
Press Arm Mount
Step 7: Attach Left and Right Top Beam Plates to Main Upright using:
Two (4“ Hex Bolts)
Two (1“ Hex Bolts)
Note: Finger Tighten Only Six (3/8” Flat Washers)
Two (3/8” Lock Nuts)
NOTE: Hang Press Arm Mount from Top Beam Plates as Plates are attached.
Page 10
STEP 7
