Inspire M1 User Manual

M1 PARTS & HARDWARE LIST
Item Parts Description Qty
Qty
Rec'd
Item Hardware Description Qty
Qty
Rec'd
1 Main Base 1 1 Bolt, 5/16-18 x 1-1/4" L (Shoulder) 3
2 Rear Base 1 2 Bolt, 3/8-16 x 1/2" L (Button Head) 2
3 Backing Plate 1 3 Bolt, 3/8-16 x 1/2" L 2
4 Foot Plate 1 4 Bolt, 3/8-16 x 1" L 6
5 Main Upright 1 5 Bolt, 3/8-16 x 1 1/2" L 2
6 Top Beam Plates 2 6 Bolt, 3/8-16 x 1 3/4" L 5
7 Press Arm Mount 1 7 Bolt, 3/8-16 x 2" L 4
8 Press Arm Bearings 2 8 Bolt, 3/8-16 x 2 1/4" L 2
9 Left Press Arm 1 9 Bolt, 3/8-16 x 2 1/2" L 1
10 Right Press Arm 1 10 Bolt, 3/8-16 x 2 3/4" L 2
11 Left Swing Arm 1 11 Bolt, 3/8-16 x 3" L 3
12 Right swing Arm 1 12 Bolt, 3/8-16 x 3 3/4" L 8
13 Lat Bar Holders 2 13 Bolt, 3/8-16 x 4" L 6
14 Guide Rods 2 14 Bolt, 3/8-16 x 4 3/4" L 1
15 Shroud Plate 1 15 Bolt, 3/8-16 x 5" L 1
16 Shroud Plate Assembly 1 16 Bolt, 3/8-16 x 5 3/4" L 1
17 Floating Pulley Plates 2
18 Floating Pulley Bracket 1 17 3/8" Washer 67
19 Top Weight/Selector Stem 1 18 3/8" Washer, small OD 6
20 Weight Stack Risers 2 19 1/2"Hat Washers 2
21 Weight Stack Numbers 1 20 1/2" Washer 2
22 Rubber Donuts 2
23 Roller Tubes 3 21 5/16-18 Locknuts 3
24 Foam Rollers 6 22 3/8-16 Locknuts 36
25 Seat Stem 1 23 1/2-13 Locknuts 2
26 Seat Pads 2
27 Upper Cable 1 24 Spacer Tube, 3" Long 1
28 Middle Cable 1 25 Step Spacer, 1" Long 8
29 Lower Cable 1 26 Step Spacer, 1/2" Long 2
30 D handle/Ab Straps 2 27 Barrel Spacer, 1" Long 2
31 Ankle Strap 1 28 Barrel Spacer, 5/8" Long 2
32 Lat Bar 1
33 Revolving Straight Bar 1 29 Cable Adapter 1
34 Fabric Shroud 1 30 Dome Caps 2
35 Guide Rod Lube 1 31 Spring Clips 4
36 Touch-up Paint 1 32 Chain 1
33 Weight Pin 1
37 3 1/2" Pulley 14 34 6 mm Wrench 1
38 4 1/2" Pulley 2 35 Cable Balls 3
39 4 1/2" Wide Pulley 1 36 "U" Bracket for cable 3
