3/8" DIA. Bolt 5/16"DIA. Shoulder Bolt Button Head Bolt
3/8" Washer 3/8" Washer Sm. O.d. 1/2" Washer 1/4" Washer
1/2" Locknut 3/8" Locknut 5/16" Locknut Hat Washer
1/2" DIA. Bolt 3/8"DIA.Flat Head Bolt Phillips Head Screw
ACTUAL PARTS MAY BE SMALLER OR LARGER THAN SHOWN
1" 2" 3" 4" 5" 6" 7"
HARDWARE CHART
PAGE 3
