Inspire M1 - Page 22

Note: Install Hat Washer
as shown.
Press Arm
2 – ½” Washers
2 – ½” Hat Washers
2 – ½” Lock Nuts
2 – Dome Caps
Right Swing Arm
Left Swing Arm
Step 27: Attach Left and Right Swing Arms to Press Arm using: Two (½” Flat Washers)
Wrench Tighten Now Two (½” Hat Washers)
Two (½” Lock Nuts)
If Swing Arms do not swing freely, back nuts off slightly Two (Dome Caps)
Page 19
STEP 27
