Install Fabric Shroud
Shroud Plate Adjustment Bolts
Step 33: To install Fabric Shroud, start at the top front of the shroud plate and wrap the top edge
of the fabric shroud around the shroud plate. Pull tight as you wrap and make sure that
the velcro rim on the fabric shroud seals firmly to the velcro rim on the Shroud Plate.
Next, Do the same for the bottom of the fabric shroud around the bottom shroud plate.
Be sure to pull tight as fabric shroud is wrapped.
If ripples appear on the fabric shroud, undo the top of the shroud and re-wrap, pulling
Up as the shroud is wrapped. This should give a nice smooth consistency to the shroud.
(If necessary, shroud can be tightened by adjusting the Shroud Plate Adjustment Bolts.)
Page 22
STEP 33
To Next Page
