IF1200A Pilot Operating Handbook 6. Long Range Telemetry (LRT)
Figure 6 below shows the Jeti DS-12 remote control.
Figure 6. Jeti DS-12 Hand Control
Flight Mode Switch Settings on Jeti DS-12
The Flight Mode Switch in the upper-right corner of the Jeti DS-12 (see Figure 6 above) is a
three-position switch that selects between the following flight modes:
Switch Position
Flight Mode
Upper
Loiter
Middle
Position Hold
Lower
RTL (Return to Launch)
IFT Doc Num 102094, Rev 1.02 Page 8
